DC 24v Rated Voltage 10.5A Rated Current 500Nm Torque Gear Motor For Solar Tracker
Being the supplier of the largest company of solar renewable in the world, we have gathered lots of experience in design and manufacture of planetary gearbox and gear motor, and our planetary gearbox and gear motor have been exported to more than 30 countries and served over 100 large solar utility worldwidely.
Specifications of solar gear motor
| Model | PLF120 |
| Drive series | 4 |
| Ratio | 1093:1 |
| Rated output torque(N.m) | 500 |
| Max torque(N.m) | 800 |
| Rated output speed | 1.7 rpm |
| Rated current (A) | 10.5 |
| Rated voltage(v) | 24 |
| Noise (db) | ≤60 |
| Working temperature(℃) | -40~80 |
Competitive Advantages
► ODM &OEM ► Noise Test ► Life Test
► Low noise, low backlash, high efficiency ► Water-proof Test ► High-low temperature test
► Long working life ► Impact Test ► Air-tight test
► 100% quality checked and guaranteed ► Salt Spray Test
Planetary gearbox and gear motor solutions, you can count on us. To be the most trustable planetary gearbox and gear motor manufacturer is what we pursue always.
FAQ
1. Are you manufacturer?
Yes, we are the manufacturer in China.
2. What information shall we give before placing a purchase order?
A) Motor specifications, ratio, output speed, output rated torque, backlash and noise requirements, connection type.
B) Purchase quantity
C) Other particular requirements
3. What applications are your gearboxes being used?
Our gearboxes widely used in the applications of solar energy, AGV, robot arms, textile, food processing, chemical industry, automation production line, environment protection, logistics and etc.
4. Would you customize for special requirements?
Yes, we have design and development team with over 10 years experience in this field.
5. Can I come to your company to visit?
Yes, you can come to our company to visit at anytime
